α-Pinene inhibits tumor invasion through downregulation of nuclear factor (NF)-κB-regulated matrix metalloproteinase-9 gene expression in MDA-MB-231 human breast cancer cells
Applied Biological Chemistry volume 59, pages 511–516 (2016)
2,6,6-Trimethylbicyclo[3.1.1]hept-2-ene (α-Pinene) is an organic compound of the terpene class found in the essential oil of many plants. In this study, the inhibitory effect of α-pinene on tumor invasion in highly metastatic MDA-MB-231 human breast cancer cells was evaluated. α-Pinene inhibited tumor necrosis factor (TNF)-α-induced invasiveness of MDA-MB-231 cells as revealed by three-dimensional spheroid invasion assay. Further analysis showed that α-pinene reduced TNFα-induced matrix metalloproteinase-9 gene promoter activation and mRNA expression in a dose-dependent manner. In addition, α-pinene treatment attenuated TNFα-induced nuclear factor κB (NF-κB) activation and NF-κB-dependent transcriptional activity. These results suggest that α-pinene has a significant effect on the inhibition of tumor invasion and may potentially be developed into an anti-metastatic drug.
Tumor necrosis factor alpha (TNFα) is one of the major cytokines involved in controlling systemic inflammation and is produced by various types of cells, including macrophages, lymphocytes, natural killer cells, neutrophils, mast cells, and fibroblasts. Tumor cells at a primary site interact with nearby stromal cells creating tumor microenvironment (Balkwill et al. 2012), which may influence tumor growth, invasion, and metastasis (Friedl and Alexander 2011). In tumor microenvironment, TNFα is produced by tumor and tumor-associated stromal cells, which in turn promote tumor invasion and metastasis through proteolysis of extracellular matrix proteins (Balkwill 2009). Matrix metalloproteinases are zinc-containing proteases involved in tissue remodeling by degrading extracellular matrix proteins. Among them, matrix metalloproteinase-9 (MMP-9) is a 92 kDa type IV collagenase (also known as gelatinase-B) that plays a critical role in the migration and invasion of tumor cells through the breakdown of basement membranes (Deryugina and Quigley 2006).
2,6,6-Trimethylbicyclo[3.1.1]hept-2-ene (α-Pinene) (Fig. 1(A)) is a naturally occurring monoterpene commonly found in essential oils of rosemary and many species of pine trees, and may possess anti-inflammatory, bronchodilator, hypoglycemic, sedative, antioxidant, and broad-spectrum antibiotic activities (Mercier et al. 2009; da Silva et al. 2012). In a recent study, α-pinene isolated from pine needle oil showed anti-proliferative effects on hepatic carcinoma BEL-7402 cells through induction of cell cycle arrest at the G2/M phase (Chen et al. 2015). However, the effect of α-pinene on tumor invasion is currently unknown. In this study, we examined the effect of α-pinene on the expression of MMP-9 mRNA in highly metastatic MDA-MB-231 human breast cancer cells. Our results reveal that α-pinene inhibits TNFα-induced MMP-9 gene expression and invasive capability of MDA-MB-231 cells through the inhibition of nuclear factor kappa B (NF-κB) activity.
Materials and methods
Cells and chemicals
MDA-MB-231 human breast cancer cells were obtained from the American Type Culture Collection (Manassas, VA, USA) and maintained in Dulbecco’s modified Eagle medium containing 10 % HyClone™ fetal bovine serum (Thermo Scientific, USA) at 37 °C in a 5 % CO2 atmosphere. α-Pinene and TNFα were purchased from Sigma-Aldrich (St. Louis, MO, USA).
Three-dimensional (3-D) spheroid cell invasion assay
Three-dimensional invasion assay was performed using Cultrex 3-D Spheroid Cell Invasion Assay kit (Trevigen, Inc., Gaithersburg, MD, USA) as described previously (Lee et al. 2015). Briefly, MDA-MB-231 cells were cultured for 7 days in a spheroid formation extracellular matrix to drive aggregation and spheroid formation of cells, followed by the addition of an invasion matrix composed of basement membrane proteins and medium, with and without 10 ng/mL TNFα in the absence and presence of 50 μM α-pinene. Cell invasion was visualized with a Nikon Eclipse TS100 microscope (Nikon Instruments Inc., Tokyo, Japan) equipped with a digital sight camera.
Reverse transcription polymerase chain reaction (RT-PCR) and quantitative real-time PCR
MDA-MB-231 cells were treated with different concentrations of α-pinene for 18 h, and total RNA was extracted using Isol-RNA lysis reagent (5 PRIME, Gaithersburg, MD, USA). The first-strand cDNA was synthesized using an iScript cDNA synthesis kit (Bio-Rad Laboratories, Hercules, CA, USA), according to the manufacturer’s instruction. PCR was performed as described previously (Shin et al. 2013b). The amplified products were subjected to electrophoresis in a 1 % agarose gel. Relative expression levels of mRNAs were measured by quantitative real-time PCR with a TaqMan-iQ™ supermix kit (Bio-Rad) using the Bio-Rad iCycler iQ™ thermal cycler according to the manufacturer’s instruction. The TaqMan™ fluorogenic probes and gene-specific PCR primers for MMP-9 and glyceraldehyde-3-phosphate dehydrogenase (GAPDH) were designed as described elsewhere (Shin et al. 2013b). The relative fold changes were normalized to GAPDH mRNA in the same sample.
NF-κB-dependent transcriptional activity assay
MDA-MB-231 cells cultured in 12-well plates were transfected with 0.1 μg of the 5 × NF-κB-Luc plasmid. At 24-h post-transfection, cells were treated with 10 ng/mL TNFα in the absence and presence of α-pinene along with 50 ng of the pRL-null plasmid encoding Renilla luciferase, as described previously (Lee et al. 2015). Firefly and Renilla luciferase activities were measured using the Dual-Glo luciferase assay system (Promega, Madison, WI, USA) and normalized to Renilla activity. The luminescence was measured with a Centro LB960 luminometer (Berthold Technologies, Bad Wildbad, Germany).
MMP-9 promoter reporter assay
Construction of the MMP-9 promoter, pMMP9(–925/+13)_Luc was described elsewhere (Shin et al. 2010). For luciferase promoter reporter assay, MDA-MB-231 cells were seeded onto 12-well plates and transfected with 0.5 µg of the pMMP9(–925/+13)_Luc using Lipofectamine 2000 (ThermoFisher Scientific, Waltham, MA, USA) as described previously (Shin et al. 2010). To monitor transfection efficiency, 50 ng of the pRL-null plasmid encoding Renilla luciferase was included in all the samples. At 48-h post-transfection, cells were treated with 10 ng/mL TNFα in the absence and presence of α-pinene. After 8 h, cells were collected and the firefly luciferase activities were measured and normalized to Renilla activities using the Dual-Glo luciferase assay system. Luminescence was measured using a Centro LB960 luminometer.
MDA-MB-231 cells were lysed, and immunoblotting was performed as described previously (Shin et al. 2013a). Antibodies specific to phosph-IKKα/β (Ser176/180), phospho-RelA (Ser536), and phospho-IκB (Ser32) were obtained from Cell Signaling Technology (Beverly, MA, USA). Antibodies against GAPDH were obtained from Santa Cruz Biotechnology (Santa Cruz, CA, USA). Signals were detected using an enhanced chemiluminescence detection system (GE Healthcare, Piscataway, NJ, USA).
MDA-MB-231 cells plated on coverslips were either untreated or treated with 10 ng/mL TNFα in the absence and presence of 50 μM α-pinene for 30 min. They were then fixed with 4 % paraformaldehyde and permeabilized using 0.1 % Triton X-100, as described previously (Shin et al. 2013a). Briefly, primary antibodies specific to α-tubulin and phospho-p65/RelA (Ser536) were preincubated for 2 h, followed by incubation with Alexa Fluor 488-conjugated (Invitrogen; green signal for α-tubulin) and Alexa Fluor 555-conjugated secondary antibodies (Invitrogen; red signal for phospho-RelA) for 30 min. Nuclear DNA (blue signal) was stained with 1 μg/mL Hoechst 33258 (Sigma-Aldrich) for 10 min. Stained cells were examined under an EVOS f1 fluorescence microscope (Advanced Microscopy Group, Bothell, WA, USA).
Statistical analysis was performed by the Student’s t test or two-factor ANOVA using the InStat version 3.0 software (GraphPad Software Inc., La Jolla, CA, USA). A P value of <0.05 was considered statistically significant. Each experiment was repeated at least three times. Data are presented as the mean ± SD.
Results and discussion
TNFα promotes tumor invasion and metastasis by stimulating the expression of MMPs in many cancer cells (Rao et al. 1999; Van den Steen et al. 2002; Lin et al. 2008; Joyce and Pollard 2009). The effect of α-pinene on the invasion of MDA-MB-231 cells was examined using a 3-D spheroid culture system (Fig. 1(B)) where control cells (vehicle) were grown into non-invasive aggregates. However, treatment of cells with 10 ng/mL TNFα resulted in cell invasion out of the spheroid into the extracellular matrix as spindle-like protrusions. However, the presence of α-pinene drastically reduced the TNFα-induced invasiveness of spheroidal cells, suggesting that α-pinene inhibits TNFα-induced invasion of MDA-MB-231 cells.
As MMP-9 plays an important role in tumor invasion and metastasis (Ura et al. 1989), the effect of α-pinene on the expression of MMP-9 mRNA in MDA-MB-231 cells was investigated. RT-PCR analysis showed that α-pinene dose dependently inhibited TNFα-induced MMP-9 mRNA expression (Fig. 2(A)). To precisely measure the change in MMP-9 transcript expression, quantitative real-time PCR analysis was performed. Treatment with TNFα alone resulted in a 12.0-fold increase in MMP-9 mRNA level; however, this decreased to 8.5-, 1.8-, and 0.9-fold upon pretreatment with 20, 50, and 100 μM α-pinene, respectively (Fig. 2(B)). To determine whether α-pinene affects MMP-9 promoter activity, MDA-MB-231 cells were transiently transfected with the MMP-9 promoter reporter construct, pMMP9(-925/+13)_Luc, and luciferase activity measured. The result showed that treatment with α-pinene dose dependently reduced TNFα-induced MMP-9 promoter reporter activity (Fig. 3). These data suggest that α-pinene inhibits TNFα-induced MMP-9 mRNA expression at the transcriptional level.
The molecular mechanism underlying the α-pinene-induced downregulation of MMP-9 gene expression was subsequently investigated. The transcription factor NF-κB controls the production of multiple inflammatory cytokines and triggers pathological conditions in chronic inflammatory diseases (Barnes and Karin 1997). In tumor microenvironment, NF-κB plays an essential role in the regulation of MMP-9 gene expression (Han et al. 2001). TNFα stimulates the inhibitor of κB kinase (IκB kinase, or IKK), which subsequently phosphorylates IκB on serine-32, leading to the degradation of IκB and eventual activation of p65/RelA NF-κB. Since TNFα stimulates NF-κB in diverse cell types (Pikarsky et al. 2004), the effect of α-pinene on TNFα-induced NF-κB activation was tested. MDA-MB-231 cells were treated with TNFα in the absence and presence of α-pinene, and the activation status of IKK, IκB, and p65/RelA was examined by immunoblot analysis. As shown in Fig. 4(A), α-pinene dose dependently reduced TNFα-induced phosphorylation of IKK (serine-176/180), IκB (serine-32), and p65/RelA NF-κB (serine-536). Moreover, α-pinene attenuated TNFα-induced NF-κB-dependent transcriptional activity in a dose-dependent manner (Fig. 4(B)). Immunofluorescent microscopic analysis showed that phosphorylation of p65/RelA (serine-536) in the nucleus was evident upon TNFα stimulation, whereas phosphorylation was barely detectable in the presence of α-pinene (Fig. 5). These results suggest that α-pinene reduces TNFα-induced MMP-9 expression by inhibiting the NF-κB signaling pathway.
Phosphatidylinositol-3-kinase (PI3K) is a ubiquitous intracellular lipid kinase capable of phosphorylating the position 3 hydroxyl group of the inositol ring of phosphatidylinositol. PI3K and its downstream protein kinase B (PKB, also known as AKT) participate in multiple cellular functions, including cell proliferation, differentiation, motility, and survival (Downes and Carter 1991). It has been reported that PKB plays an important role in the activation of NF-κB by phosphorylating IKKα (Ozes et al. 1999; Madrid et al. 2000, 2001). 1-2,4-Dihydroxy-3-(3-methyl-but-2-enyl)-phenyl]-3-(4-hydroxyphenyl)-propenone (Isobavachalcone), a natural chalcone derivative, inhibits PKB through binding to the ATP-binding site (Jing et al. 2010). We previously demonstrated that DK-139 (2-hydroxy-3′,5,5′-trimethoxychalcone) inhibited lipopolysaccharide-induced NF-κB activity via direct binding to PKB (Lee et al. 2012). Thus, it is possible to hypothesize that α-pinene inhibits IKK through the inhibition of PKB similar to DK-139. α-Pinene could also inhibit PKB and its upstream activators, PI3K and mTORC2 (Sarbassov et al. 2005). To clarify this point, future studies will be aimed at identifying the molecular target of α-pinene.
In summary, the present study demonstrates that α-pinene inhibits the invasiveness of highly metastatic MDA-MB-231 human breast cancer cells. Our experiments show that α-pinene inhibited TNFα-induced MMP-9 mRNA expression and TNFα-mediated NF-κB activity by suppressing IKK. These findings suggest that α-pinene has the potential to be developed into an anti-metastatic agent against highly metastatic malignancy.
Balkwill F (2009) Tumour necrosis factor and cancer. Nat Rev Cancer 9:361–371
Balkwill FR, Capasso M, Hagemann T (2012) The tumor microenvironment at a glance. J Cell Sci 125:5591–5596
Barnes PJ, Karin M (1997) Nuclear factor-kappaB: a pivotal transcription factor in chronic inflammatory diseases. N Engl J Med 336:1066–1071
Chen W, Liu Y, Li M, Mao J, Zhang L, Huang R, Jin X, Ye L (2015) Anti-tumor effect of alpha-pinene on human hepatoma cell lines through inducing G2/M cell cycle arrest. J Pharmacol Sci 127:332–338
da Silva AC, Lopes PM, de Azevedo MM, Costa DC, Alviano CS, Alviano DS (2012) Biological activities of alpha-pinene and beta-pinene enantiomers. Molecules 17:6305–6316
Deryugina EI, Quigley JP (2006) Matrix metalloproteinases and tumor metastasis. Cancer Metastasis Rev 25:9–34
Downes CP, Carter AN (1991) Phosphoinositide 3-kinase: a new effector in signal transduction? Cell Signal 3:501–513
Friedl P, Alexander S (2011) Cancer invasion and the microenvironment: plasticity and reciprocity. Cell 147:992–1009
Han YP, Tuan TL, Hughes M, Wu H, Garner WL (2001) Transforming growth factor-beta-and tumor necrosis factor-alpha-mediated induction and proteolytic activation of MMP-9 in human skin. J Biol Chem 276:22341–22350
Jing H, Zhou X, Dong X, Cao J, Zhu H, Lou J, Hu Y, He Q, Yang B (2010) Abrogation of Akt signaling by Isobavachalcone contributes to its anti-proliferative effects towards human cancer cells. Cancer Lett 294:167–177
Joyce JA, Pollard JW (2009) Microenvironmental regulation of metastasis. Nat Rev Cancer 9:239–252
Lee YH, Jeon SH, Kim SH, Kim C, Lee SJ, Koh D, Lim Y, Ha K, Shin SY (2012) A new synthetic chalcone derivative, 2-hydroxy-3′,5,5′-trimethoxychalcone (DK-139), suppresses the Toll-like receptor 4-mediated inflammatory response through inhibition of the Akt/NF-kappaB pathway in BV2 microglial cells. Exp Mol Med 44:369–377
Lee MS, Koh D, Kim GS, Lee SE, Noh HJ, Kim SY, Lee YH, Lim Y, Shin SY (2015) 2-Hydroxy-3,4-naphthochalcone (2H-NC) inhibits TNFalpha-induced tumor invasion through the downregulation of NF-kappaB-mediated MMP-9 gene expression. Bioorg Med Chem Lett 25:128–132
Lin CC, Tseng HW, Hsieh HL, Lee CW, Wu CY, Cheng CY, Yang CM (2008) Tumor necrosis factor-[alpha] induces MMP-9 expression via p42/p44 MAPK, JNK, and nuclear factor-[kappa]B in A549 cells. Toxicol Appl Pharmacol 229:386–398
Madrid LV, Wang CY, Guttridge DC, Schottelius AJ, Baldwin AS Jr, Mayo MW (2000) Akt suppresses apoptosis by stimulating the transactivation potential of the RelA/p65 subunit of NF-kappaB. Mol Cell Biol 20:1626–1638
Madrid LV, Mayo MW, Reuther JY, Baldwin AS Jr (2001) Akt stimulates the transactivation potential of the RelA/p65 Subunit of NF-kappa B through utilization of the Ikappa B kinase and activation of the mitogen-activated protein kinase p38. J Biol Chem 276:18934–18940
Mercier B, Prost J, Prost M (2009) The essential oil of turpentine and its major volatile fraction (alpha- and beta-pinenes): a review. Int J Occup Med Environ Health 22:331–342
Ozes ON, Mayo LD, Gustin JA, Pfeffer SR, Pfeffer LM, Donner DB (1999) NF-kappaB activation by tumour necrosis factor requires the Akt serine-threonine kinase. Nature 401:82–85
Pikarsky E, Porat RM, Stein I, Abramovitch R, Amit S, Kasem S, Gutkovich-Pyest E, Urieli-Shoval S, Galun E, Ben-Neriah Y (2004) NF-kappaB functions as a tumour promoter in inflammation-associated cancer. Nature 431:461–466
Rao VH, Singh RK, Delimont DC, Finnell RH, Bridge JA, Neff JR, Garvin BP, Pickering DL, Sanger WG, Buehler BA, Schaefer GB (1999) Transcriptional regulation of MMP-9 expression in stromal cells of human giant cell tumor of bone by tumor necrosis factor-alpha. Int J Oncol 14:291–300
Sarbassov DD, Guertin DA, Ali SM, Sabatini DM (2005) Phosphorylation and regulation of Akt/PKB by the rictor-mTOR complex. Science 307:1098–1101
Shin SY, Kim JH, Baker A, Lim Y, Lee YH (2010) Transcription factor Egr-1 is essential for maximal matrix metalloproteinase-9 transcription by tumor necrosis factor alpha. Mol Cancer Res 8:507–519
Shin SY, Kim JH, Yoon H, Choi YK, Koh D, Lim Y, Lee YH (2013a) Novel antimitotic activity of 2-hydroxy-4-methoxy-2′,3′-benzochalcone (HymnPro) through the inhibition of tubulin polymerization. J Agric Food Chem 61:12588–12597
Shin SY, Lee JM, Lim Y, Lee YH (2013b) Transcriptional regulation of the growth-regulated oncogene alpha gene by early growth response protein-1 in response to tumor necrosis factor alpha stimulation. Biochim Biophys Acta 1829:1066–1074
Ura H, Bonfil RD, Reich R, Reddel R, Pfeifer A, Harris CC, Klein-Szanto AJ (1989) Expression of type IV collagenase and procollagen genes and its correlation with the tumorigenic, invasive, and metastatic abilities of oncogene-transformed human bronchial epithelial cells. Cancer Res 49:4615–4621
Van den Steen PE, Dubois B, Nelissen I, Rudd PM, Dwek RA, Opdenakker G (2002) Biochemistry and molecular biology of gelatinase B or matrix metalloproteinase-9 (MMP-9). Crit Rev Biochem Mol Biol 37:375–536
This study was supported by the Konkuk University research support program.
Rights and permissions
About this article
Cite this article
Kang, E., Lee, D.H., Jung, Y.J. et al. α-Pinene inhibits tumor invasion through downregulation of nuclear factor (NF)-κB-regulated matrix metalloproteinase-9 gene expression in MDA-MB-231 human breast cancer cells. Appl Biol Chem 59, 511–516 (2016). https://doi.org/10.1007/s13765-016-0175-6
- Breast cancer
- Matrix metalloproteinase-9
- Nuclear factor kappa B
- Tumor invasion
- Tumor necrosis factor alpha
